Rockwell Automation Publication 750-QS100B-EN-P - August 2020 23
Step 3: Power Up, Configure the Modular Control Profiles
Enter the Application Selection
You can add Process PID, Torque Prove, or Oil Well Pump application functionality to determine which application
parameters are present in virtual port 9. This is only needed when you are using Process PID, Torque Prove, or Oil Well
Pump. The following options are available:
• None - leaves port 9 empty. This is the default setting
• Process PID only - provides a PID regulator for process applications in port 9. Use Process PID for pressure or
flow transducers on fan or pump applications; you can also use it for tension transducers on winding applications.
• Torque Prove - provides a mechanism for coordinating the motor and mechanical brake on lifting applications.
This selection loads these parameters and the Process PID parameters into port 9.
• Oil Well Pump - provides a mechanism for pump jack and progressive cavity pump applications
1. Navigate to parameter 0:70 [Application Sel].
2. Press the EDIT soft key.
3. Edit the value to 0 ‘None’, 1 ‘ProcPID Only’, 2 ‘Torque Prove’, or 3 `OilWell Pump', choosing the option
corresponding to the data collected in Tab l e 3 o n pa g e 15
.
4. Press the ENTER soft key.
Enter the Embedded Logic Selection
Selecting DeviceLogix as the embedded logic source loads embedded logic parameters into port 9 following a reset or
power cycle. These parameters contain the default values.
1. Navigate to parameter 0:72 [Emb Logic Select].
2. Press the EDIT soft key.
3. Edit the value to 0 ‘None’ or 1 ‘DeviceLogix’, choosing the option corresponding to the data collected in Tab l e 3
.
4. Press the ENTER soft key.
