Rockwell Automation Publication 750-QS100B-EN-P - August 2020 53
Appendix A
Reference Information
This appendix provides reference information that supplements the start-up and configuration procedure.
Reset Device
There are two Reset Device procedures. You can use either method to reset the device:
• Cycle Power to the Drive and Control Pod
• Use the HIM Reset Device Function
Cycle Power to the Drive and Control Pod
1. De-energize the external 24V DC power source that is connected to the drive 24V Auxiliary Power terminals, if
used.
2. De-energize the AC power supply to the drive AC input. To ensure that the drive is adequately de-energized, wait
3 minutes or wait until all lights are off in the drive cabinet.
3. Energize the AC power supply to the drive AC input.
4. Energize the 24V Auxiliary Power supply source, if used.
Use the HIM Reset Device Function
1. Ensure that the drive is not communicating to a controller. You cannot use the HIM reset device function while
the drive is communicating to a controller.
2. Access the HIM Status screen. The AC power and 24V Auxiliary Power sources can be energized when using the
HIM Reset Device function.
3. Use the HIM navigation keys to scroll to the port of the device you want to reset. Typically this is port 0 Host
drive.
4. Press the key and use the HIM navigation keys to scroll to the DIAGNOSTIC folder.
5. Use the HIM navigation keys to select 'Reset Device'.
6. Press the key. When the confirmation dialog box opens, press the ENTER soft key to reset the device. The
device restarts. To cancel Reset Device, press the ESC soft key.
IMPORTANT If the 24V Auxiliary Power supply source is energized, cycling the AC power does not reset the control pod port devices.
