Rockwell Automation Publication 750-QS100B-EN-P - August 2020 47
Step 9: Set Up Start/Stop
2. Edit the value using the HIM navigation keys to assign the I/O module port, and digital input status bit,
parameter nn:1 [Dig In Sts], corresponding to the Stop digital input terminal you recorded in Tab le 2 on pa ge 10
.
For example, the Stop push button is wired to terminal DI 0 of a 22-Series (20-750-22xxx-xxxx) I/O module in
port 4. Navigate to parameter 0:108 [DI M Stop]. Press the EDIT soft key. Edit the value using the HIM
navigation keys to select the I/O module in port 4. Press the ENTER soft key. Use the HIM navigation keys to
select parameter 4:1 [Dig In Sts]. Press the ENTER soft key. Use the HIM navigation keys to select bit 0. Press the
ENTER soft key.
3. Navigate to parameter 0:117 [DI M Start]. Press the EDIT soft key.
4. Edit the value using the HIM navigation keys to assign the I/O module port and digital input status bit, and the
parameter nn:1 [Dig In Sts], corresponding to the motor side Start digital input terminal you recorded in Ta b le 2
.
For example, the Start push button is wired to terminal DI 1 of a 22-Series (20-750-22xxx-xxxx) I/O module in
port 4. Navigate to parameter 0:117 [DI M Start]. Press the EDIT soft key. Edit the value using the HIM
navigation keys to select the I/O module in port 4. Press the ENTER soft key. Use the HIM navigation keys to
select parameter 4:1 [Dig In Sts]. Press the ENTER soft key. Use the HIM navigation keys to select bit 1. Press the
ENTER soft key.
Two-Wire Control
Examples of wiring option module digital I/O can be found in the PowerFlex 750-Series I/O, Feedback, and Power
Option Modules Installation Instructions, publication 750-IN111
.
1. Navigate to parameter 0:120 [DI M Run]. Press the EDIT soft key.
2. Edit the value using the HIM navigation keys to assign the I/O module port and digital input status bit, and
parameter 0:1 [Dig In Sts], corresponding to the motor side Run digital input terminal you recorded in Ta b l e 2
.
For example, the Run input is wired to terminal DI 2 of a 22-Seriex (20-750-22xxx-xxxx) I/O module in port 4.
Navigate to parameter 0:120 [DI M Run]. Press the EDIT soft key. Edit the value using the HIM navigation keys
to select the I/O module in port 4. Press the ENTER soft key. Use the HIM navigation keys to select parameter
4:1 [Dig In Sts]. Press the ENTER soft key. Use the HIM navigation keys to select bit 2. Press the ENTER soft
key.
Embedded EtherNet/IP Interface
The logic command word from the controller starts and stops the drive without any special parameter settings.
IMPORTANT The drive must be stopped.
