Rockwell Automation Publication 750-QS100B-EN-P - August 2020 49
Step 11: Configure Outputs
Analog Outputs
Select the configuration according to the analog output wiring you recorded in Table 2 on page 10.
Examples of wiring option module analog I/O can be found in the PowerFlex 750-Series I/O, Feedback, and Power
Option Modules Installation Instructions, publication 750-IN111
.
Use this table to determine the parameters associated with I/O option module analog output parameters, where nn is
port where the I/O module is installed.
1. Navigate to port nn, parameter 75 [Anlg Out0 Sel] for I/O terminal <Ao0>, or parameter 85 [Anlg Out1 Sel] for
I/O terminal <Ao1>. Press the EDIT soft key.
2. Edit the value using the HIM navigation keys to select the port and parameter corresponding with the analog
output functions you recorded in Tabl e 2
.
For example, when using a 22-Series (20-750-22xxx-xxxx) in port 4 with a motor current meter wired to analog
output terminals <Ao0+> and <Ao0->. Navigate to port 4, parameter 75 [Anlg Out0 Sel]. Press the EDIT soft
key. Edit the value using the HIM navigation keys to select port 10. Press the ENTER soft key. Use the HIM
navigation keys to select the motor side inverter 'Output Current', parameter 10:3 [Output Current]. Press the
ENTER soft key.
3. Navigate to the port and parameters for the I/O option card. Edit each of the parameter values to match the
application requirements. See the PowerFlex Drives with TotalFORCE Control Programming Manual,
publication 750-PM100
, for more information about setting these parameters.
In the previous example, you would navigate to port 4 and edit values for these parameters: 4:70 [Angl Out Type]
bit 0, 4:71 [Anlg Out Abs] bit 0, 4:78 [Anlg Out0 DataHi], 4:79 [Anlg Out0 DataLo], 4:80 [Anlg Out0 Hi], and
4:81 [Anlg Out0 Lo].
Terminal Name Option Module Related Parameters
Ao0+, Ao0- Analog Out 0 11-Series
22-Series
nn:70 [Anlg Out Type], bit 0
nn:71 [Anlg Out Abs], bit 0
nn:75 [Anlg Out0 Sel]
nn:76 [Anlg Out0 Stpt]
nn:77 [Anlg Out0 Data]
nn:78 [Anlg Out0 DataHi]
nn:79 [Anlg Out0 DataLo]
nn:80 [Anlg Out0 Hi]
nn:81 [Anlg Out0 Lo]
nn:82 [Anlg Out0 Val]
Ao1+, Ao1- Analog Out 1 22-Series nn:70 [Anlg Out Type], bit 1
nn:71 [Anlg Out Abs], bit 1
nn:85 [Anlg Out1 Sel]
nn:86 [Anlg Out1 Stpt]
nn:87 [Anlg Out1 Data]
nn:88 [Anlg Out1 DataHi]
nn:89 [Anlg Out1 DataLo]
nn:90 [Anlg Out1 Hi]
nn:91 [Anlg Out1 Lo]
nn:92 [Anlg Out1 Val]
