Publication 2100-IN012C-EN-P - April 2009 23
General Information Chapter 1
Handling
Lifting with a forklift, overhead lifting, sling lifting, and pipe or rod
rolling are methods that can be used to handle vertical sections. See
the following tables for typical weights and dimensions for standard
20 in. (508 mm) wide and 15 in. (381 mm) or 20 in. (508 mm) deep
sections. For sizes not listed consult your local Rockwell Automation
Sales Office.
Shipping Weights and Dimensions - Standard Packaging
Standard
Packing
(1)
(1)
Standard packing for shipments in the United States and Canada. The MCC shipping block is
mounted on a skid and covered in clear plastic wrap. This packaging is not watertight or waterproof.
Weight
kg (lb),
approx.
Height
in. (cm),
approx.
Depth
in. (cm),
approx.
Width
in. (cm),
approx.
Front mounted
1-section block
227 (500) 96 (244) 36 (91) 43 (109)
Front mounted
2-section block
454 (1000) 96 (244) 36 (91) 43 (109)
Front mounted
3-section block
680 (1500) 96 (244) 36 (91) 63 (160)
Back-to-back
2-section block
454 (1000) 96 (244) 42 (107) 43 (109)
Back-to-back
4-section block
816 (1800) 96 (244) 42 (107) 43 (109)
Back-to-back
6-section block
998 (2200) 96 (244) 42 (107) 63 (160)
