Publication 2100-IN012C-EN-P - April 2009 65
Operator Handle and Unit Interlock Chapter 6
Locking Vertical Handles in OFF/O Position
Lock Horizontal Operating Handles in the OFF/O Position
Some units use a horizontal operating handle. The horizontal
operating handle can be locked in the OFF/O position by putting the
shackle of the lock through the open slotted area to the left of the
operator handle.
Locking a Horizontally Mounted Operating Handle in OFF/O Position
Small and Medium Vertical Handle Large Handle
