Chapter 6 Operator Handle and Unit Interlock
Defeater Lever for Horizontal Operating Handle
Locking Provisions
Refer to the following sections for locking provisions.
Lock Vertical Operating Handles in the OFF/O Position
To lock the small, medium, and large operator handle in the OFF/O
position, put the shackle of the lock through the opening in the
operator handle assembly. The opening can accommodate up to three
padlocks.
ATTENTION
When working on or near energized electrical equipment,
follow established electrical safety-related work practices.
Refer to NFPA 70E Standard for Electrical Safety in the
Workplace.
Personal protective equipment (PPE) is not shown for clarity.
ATTENTION
When working on or near energized electrical equipment,
follow established electrical safety-related work practices.
Refer to NFPA 70E Standard for Electrical Safety in the
Workplace.
