73Publication 2100-IN012C-EN-P - April 2009 73
Chapter
7
Final Check List Before Energizing
Introduction
This section provides guidance for the startup of a newly installed
MCC.
We recommend making an itemized list including:
• serial number.
• number of sections.
• number of units and their corresponding voltage.
• current ratings.
• horsepower ratings
• types of circuits.
• fuse sizes.
• circuit breaker ratings and trip settings.
• heater elements requirements.
• other important data.
The itemized list could be modeled after the MCC layout drawings
supplied with each MCC. This itemized list should be saved in a file
along with other data for the MCC such as, component manuals,
heater element instructions, MCC manuals, and wiring diagrams.
Blank sample forms are provided at the end of this chapter.
Pre-Energizing Check
Procedure
The following procedures should be executed by a ‘qualified person’
as defined by NEMA Standards Publication / No. ICS 2.3, Instructions
for the Handling, Installation, Operation and Maintenance of Motor
Control Centers, Section 1 as follows:
1.4 Qualified Person
For the purpose of this guide, a qualified person is one who is
familiar with the installation, construction and operation of the
equipment and the hazards involved. In addition, he or she has
the following qualifications:
1.4.1
Is trained and authorized to energize, de-energize, clear,
ground and tag circuits and equipment in accordance with
established safety practices.
