Publication 2100-IN012C-EN-P - April 2009 83
Final Check List Before Energizing Chapter 7
Arc Resistant MCC with Insulating Sheet (15 in. deep, right side visible)
ATTENTION
Arc resistant MCCs are provided with an insulating sheet for
each center-end closing plate. This insulation sheet must be in
place in order to maintain the arc resistant capabilities of the
MCC.
End Closing Plate
Insulation Sheet
