• ADJUSTING
THE
HEADPHONE SETTINGS:
1.
Press and hold SET.
2.
Rotate the Select Knob counter clockwise (left) until the Console Display reads
"HEADPHONE", and place the cursor on the top line.
3.
Release SET.
4.
Rotate the Alpha Dial to select the setting to be adjusted ("VOLUME",
"BALANCE", "BASS", or "TREBLE").
5.
Turn the Select Knob clockwise (right) to place the cursor on the bottom
line.
6.
Rotate the Alpha Dial to set the desired value.
AUXILIARY
INPUTS
The Rodgers 960
is
equipped with stereo Auxiliary Input Jacks (one for the left channel
and one for the right channel) located on the Connector Panel under the keydesk to the right.
When using these input jacks, audio signals from other sound generating devices like
synthesizers, MIDI sound modules, and tape players are mixed into the organ's main audio
system. A series
of
Console Display menu controls
is
used to adjust the characteristics
of
the
Auxiliary Input sound.
• ADJUSTING
THE
AUXILIARY INPUTS:
1.
Press and hold the SET piston.
2.
Turn the Select Knob counter clockwise (left) to "AUXILIARY", and place the
cursor on the top line.
3.
Release SET.
4.
Rotate the Alpha Dial to select the desired control.
5.
Turn the Select Knob clockwise (right) to place the cursor on the bottom
line.
6.
Rotate the Alpha Dial to obtain the desired effect. Note:
An
Audio Save may
be
performed to save this setting
as
the default. Please refer
to
the "Audio
Save"section.
STERF,O
LINE
OUTPUTS
The Rodgers 960
is
equipped with stereo Line Outputs also located on the Connector
Panel. When using these outputs the divisions
of
the organ (Great, Swell, Choir and Pedal) are
heard
in
stereo. There
is
no specific channel assignment (left or right) given to these divisions.
The volume may be adjusted by performing the following procedure:
• ADJUSTING
THE
STEREO LINE OUTPUTS:
1.
Press and hold the SET piston.
2.
Turn the Select Knob counter clockwise (left) to
"LINE
OUT GAIN".
3.
Release SET.
27
