4 Updates of version P2.00
1. Maintaining the functions of version r1.65, the memory of FLASH has been expanded from 64k to 256k in view
of future developments
2. Added connector to plug in the WiFi module (for future use)
3. Improved management of persistent AP command
4. Improved management of guaranteed closure
5. Improved management of engine timing errors
5 Technical characteristics of product
BG30/1603
BG30/1604
BG30/2203
BG30/2204
BG30/1003/HS
BG30/1004/HS
BG30/1404/R
BG30/1504/HS BG30/1804/HS
MAINS POWER VOLTAGE 230 V ± 10% 50 Hz (115 V ±10% 50/60 Hz)
(1)
MAXIMUM MAINS POWER
ABSORPTION
180 W 190 W 200 W 190 W 240 W 230 W
INRUSH POWER 390 W 470 W 590 W 540 W 650 W 650 W
FUSES
F1 = 20A (ATO257) motor power circuit protection
F2 = T2A (ATO257) primary transformer protection
F3 = 3A(5x20 mm) accessories power supply protection
CONNECTABLE MOTORS 1
MOTOR POWER SUPPLY 36 Vac, with self-protected inverter
MOTOR TYPE sinusoidal drive brushless (ROGER BRUSHLESS)
MOTOR CONTROL TYPE WIRWSVIHƼIPHSVMIRXIHGSRXVSP*3'
RATED MOTOR POWER 85 W 100 W 140 W 120 W 160 W 160 W
MAXIMUM MOTOR POWER 350 W 420 W 530 W 480 W 590 W 590 W
MAXIMUM POWER,
FLASHING LIGHT
25 W
FLASHING LIGHT DUTY CYCLE 50%
MAXIMUM POWER 100 W 230 V - 40 W 24 V / (potential free contact)
GATE OPEN LIGHT POWER 3 W (24 V
)
MAXIMUM ACCESSORY
CURRENT ABSORPTION
20 W
OPERATING TEMPERATURE
-20°C +55°C
SOUND PRESSURE DURING USE <70 dB (A)
PR OD UC T D IM EN SI ON S
dimensions in mm 200x90x45 Weight: 0,244 kg
115V AC
(1)
BG30/1603/115 - BG30/1604/115 - BG30/2203/115 - BG30/2204/115 - BG30/1003/HS/115 -
BG30/1004/HS/115 -BG30/1504/HS/115 - BG30/1404/R/115 - BG30/1804/HS/115
The total of the absorption values of all the accessories connected must not exceed the maximum power
values shown in the table. The values are guaranteed with original ROGER TECHNOLOGY accessories ONLY.
The use of non-original accessories may lead to malfunctioning. ROGER TECHNOLOGY declines all responsibility for
incorrect or non-conforming installations.
All the connections are protected by fuses (refer to the table). The courtesy light requires an external fuse.
