10
Getting Ready
Turning the Power On/O
* Once everything is properly connected (p. 9), be sure to follow
the procedure below to turn on their power. If you turn on
equipment in the wrong order, you risk causing malfunction or
equipment failure.
* Before turning the unit on/o, always be sure to turn the volume
down. Even with the volume turned down, you might hear some
sound when switching the unit on/o. However, this is normal
and does not indicate a malfunction.
Turning the power on
1. Minimize the volume of the TD-50 and the connected
devices.
2. Press the TD-50’s [
L
] switch.
When you turn the TD-50 on, the following screen appears.
In this screen you can enable or disable the AUTO OFF function.
Button Explanation
[F1] (OFF) Button The power does not turn o automatically.
[F4] (4 HOURS)
Button
When four hours have elapsed without any pad
being struck or any operation being performed, the
unit will turn o automatically.
If the AUTO OFF function is set to “OFF,” this screen won’t appear.
MEMO
If a pad that supports digital connection is connected, the pad
setting screen might appear. For details, refer to “Settings for
pads that support digital connection” (p. 9).
3. Power-on the connected devices, and adjust the volume.
Turning the power o
NOTE
Settings that you edit on the TD-50 are saved when you turn o
the unit. Be sure to turn o the unit by pressing the [
L
] switch.
1. Minimize the volume of the TD-50 and the connected
devices.
2. Turn o the power to the connected devices.
3. Press the TD-50’s [
L
] switch.
The screen will indicate “Please wait. Now saving...,” and the unit will
turn o when the settings have been saved.
* If you need to turn o the power completely, rst turn o the
unit, then unplug the power cord from the power outlet. Refer
to “To completely turn o power to the unit, pull out the plug
from the outlet” (Quick Start).
Making the Power Automatically Turn o After
a Time (AUTO OFF)
The power to this unit will be turned o automatically after
a predetermined amount of time has passed since it was
last used for playing music, or its buttons or controls were
operated (AUTO OFF function).
If you do not want the power to be turned o automatically,
disengage the AUTO OFF function.
* To restore power, turn the power on again.
1. Press the [SETUP] button.
2. Use the PAGE [UP] [DOWN] buttons and the function
buttons to select “AUTO OFF.”
The AUTO OFF screen appears.
3. Use the [–] [+] buttons or the dial to specify the setting of
the auto-o function.
Value Explanation
OFF The power does not turn o automatically.
4 HOURS
When four hours have elapsed without any pad
being struck or any operation being performed, the
unit will turn o automatically.
4. Press the [KIT] button to return to the DRUM KIT screen.
MEMO
If the auto-o function is set to “4 HOURS,” the message
“WARNING: AUTO OFF, The TD-50 will turn o in 30 min.” will
appear 30 minutes before turning the TD-50 o.
To Next Page
