Orion Installation and Operations Manual
11
Access Options
Field
Selection
Description
Enable Login
Y/N
Y – Login required to access the OSD with user name and password. After login,
the user will remain logged in until he explicitly logs out or an Auto Logout
has been performed. KVM Switching with Hot Keys requires the user to be
logged in.
N – No Login required.
User Matrix
Y/N
Y – User access restricted to CPU’s explicitly unlocked in the User
Matrix. User matrix mode requires user login and implies
“Enable Login“ = “Y“. KVM Switching with Hot Keys requires the user to
be logged in.
N – User Matrix disabled.
CON Matrix.
Y/N
Y – CON Port connectivity restricted to CPU’s explicitly unlocked in
the CON Matrix
N – CON Matrix disabled
Auto
Disconnect
Y/N
Y – Only active if “Enable Login“ or “„User Matrix“ are activated:
CON Port is disconnected from current CPU Port upon entering
into the OSD.
N – Current Connection is held
OSD Timeout
sec
### – Time of inactivity, after which OSD is closed automatically.
0 sec – No Timeout.
Auto Logout
min
### – Time of inactivity, after which the user at this console is logged
out from OSD access automatically.
0 min – Immediate Logout from OSD after closing the OSD.
