MODEL SOLU COMP II SECTION 1.0
DESCRIPTION AND SPECIFICATIONS
1.4 ORDERING INFORMATION
The Solu Comp II analyzers offer the choice of single or dual sensor input with measurement choices of pH/ORP
and conductivity/resistivity. The pH measurement option offers field configurable measurement units as pH, ORP,
or Redox. The conductivity measurement option has measurement unit choices of conductivity and resistivity.
Standard features include two isolated outputs, three alarm relays, customizable two-line display, and temperature
correction.
MODEL
1055 SOLU COMP II ANALYZER
CODE
MEASUREMENT 2 (Optional)
30 Contacting Conductivity
32 pH/ORP
CODE POWER
01 115/230 Vac, 50/60 Hz power
02 24 Vdc
CODE MOUNTING
10 Panel mounting enclosure
11 Pipe/Surface mounting enclosure
CODE MEASUREMENT 1 (Required Selection)
20 Contacting Conductivity
22 pH/ORP
1055 -01 -10 -20 EXAMPLE
ACCESSORIES (Weights are rounded up to nearest whole lb or 0.5 kg)
PART NUMBER DESCRIPTION WEIGHT SHIPPING WT.
23820-00 Pipe mounting kit, includes U-bolts, mounting bracket, nuts, 2 lb (1.0 kg) 4 lb (2.0 kg)
washers, and screws (complete)
23554-00 Gland fittings, PG 13.5, 5 per package 1 lb (0.5 kg) 2 lb (1.0 kg)
9240048-00 Tag, stainless steel (specify marking) 1 lb (0.5 kg) 1 lb (0.5 kg)
pH INPUT
9210012 Buffer Solution, 4.01 pH, 1 pint (473 mL) 1 lb (0.5 kg) 2 lb (1.0 kg)
9210013 Buffer Solution, 6.86 pH, 1 pint (473 mL) 1 lb (0.5 kg) 2 lb (1.0 kg)
9210014 Buffer Solution, 9.18 pH, 1 pint (473 mL) 1 lb (0.5 kg) 2 lb (1.0 kg)
CONDUCTIVITY INPUT
SS-1 0.01N Potassium Chloride, 1409 µS/cm at 25°C, 1 quart (945 mL) 2 lb (1.0 kg) 4 lb (2.0 kg)
SS-1A 0.01N Potassium Chloride, 1409 µS/cm at 25°C, 1 gallon (3785 mL) 9 lb (4.0 kg) 11 lb (5.0 kg)
SS-5 Conductivity Standard, 1000 µS/cm at 25°C, 1 quart (945 mL) 2 lb (1.0 kg) 4 lb (2.0 kg)
SS-5A Conductivity Standard, 1000 µS/cm at 25°C, 1 gallon (3785 mL) 9 lb (4.0 kg) 11 lb (5.0 kg)
SS-6 Conductivity Standard, 200 µS/cm at 25°C, 1 quart (945 mL) 2 lb (1.0 kg) 4 lb (2.0 kg)
SS-6A Conductivity Standard, 200 µS/cm at 25°C, 1 gallon (3785 mL) 9 lb (4.0 kg) 11 lb (5.0 kg)
SS-7 Conductivity Standard, 5000 µS/cm at 25°C, 1 quart (945 mL) 2 lb (1.0 kg) 4 lb (2.0 kg)
SS-7A Conductivity Standard, 5000 µS/cm at 25°C, 1 gallon (3785 mL) 9 lb (4.0 kg) 11 lb (5.0 kg)
4
