MODEL SOLU COMP II SECTION 5.0
PROGRAMMING THE ANALYZER
TABLE 5-1. DEFAULT SETTINGS
1. SENSOR-OUTPUT ASSIGNMENTS (pH, ORP, or redox is selected during Quick Start)
6. MISCELLANEOUS SETTINGS
Section
Language English 5.11
Hold off 4.5
Security code 000 (no security code) 5.7
ac power frequency 60 Hz 5.8
5. TEMPERATURE RELATED SETTINGS
Section
Units °C 5.6
Automatic temperature compensation On 5.6
Solution temperature correction Off 5.5
Isopotential pH 7.00 5.5
3. OUTPUT RANGES (pH, ORP, or redox is selected during Quick Start)
Measurement Range Section
pH 0 to 14 5.3
ORP/Redox -1400 to 1400 mV 5.3
Temperature 0 to 100°C 5.3
Sensor(s) Output 1 Output 2 Section
Single sensor pH/ORP/Redox Temperature 5.3 and 5.9
Dual sensor pH/ORP/Redox for sensor 1 pH/ORP/Redox for sensor 2 5.3 and 5.9
2. OTHER OUTPUT SETTINGS
Output Dampening 0 or 4 mA Mode Section
1 off 4 linear 5.3
2 off 4 linear 5.3
4. ALARM CONFIGURATION AND SETPOINTS
Alarm
1 2 3 Section
Assigned to Sensor 1 Sensor 1 (note) Fault 5.4
High or low High High NA 5.4
Deadband 0 0 NA 5.4
Setpoint (pH) 14 (high); 0 (low) 14 (high); 0 (low) NA 5.4
Setpoint (ORP/Redox) 1400 mV (high); -1400 mV (low) 1400 mV (high); -1400 mV (low) NA 5.4
Note: For dual sensor input, alarm 2 is assigned to sensor 2.
