73. While tailgate is rising, release push‑button before
it reaches its fully raised position.
• Tailgate should stop rising immediately the
switch is released.
• Tailgate should not lower.
• ‘Tailgate out‑of‑locks’ pictogram should
continue to display on the control panel screen.
74. Press the ‘Tailgate raise’ push‑button until the
tailgate is fully raised and then release the push‑
button.
• Check that the tailgate resumes rotating
upwards about the hinge pins until fully raised
when it should stop without noticeable judder.
• ‘Vehicle reversing’ alarm should sound while
‘Tailgate raise’ push‑button is pressed and
tailgate is rising.
75. When the tailgate is raised, the ‘Tailgate fully
raised’ pictogram should display on the control
panel screen.
76. Press the ‘Ejection plate eject’ push‑button.
Release the push‑button when the ejection plate
has reached the end of its travel.
• Ejection plate should eject smoothly without
judder.
DAILY CHECKS
3‑20
OM1R-SM-GB01R
