4.1.1 Topping up hydraulic oil
1. If topping up is necessary, thoroughly clean:
• The filler cap (1) and its surrounding area.
• Any filling equipment to be used.
1
Fig. 4-2 Filler cap
2. Unscrew the filler cap (see Fig. 4‑2, 1). Top up as
necessary to the correct level using new hydraulic
oil to the correct specification.
Temperature
Range
ISO
Grade
ISO Oil
Type
‑30° to +80° VG 46 HL mineral oil to
UNE‑EN ISO 6743‑4: 2002
Caution:
Do not mix different oil types.
3. Replace the filler cap.
4. If the hydraulic level is very low, inspect all the
hydraulic systems including waste container lifting
device, if fitted, for hydraulic oil leaks. Rectify any
leaks before operating the vehicle.
HYDRAULIC SYSTEM OIL LEVEL
4‑8
OM1R-SM-GB01R
