To configure the reader addresses:
1. Set the DIP switches or use a mobile app for the correct number of OSDP peripheral devices as given below.
Scenario Address Output
One Reader per Door
1 1
2 2
3 3
4 4
5 5
6 6
Two Readers per Door
1+2 1
3+4 3
5+6 5
3.6. R/S/D/P-825 Extension Board Setup
There are four types of expansion boards as follows:
•
R-805 – The R-805 is an optional expansion board that adds 16 outputs to the access control panel.
•
S-805 – The S-805 is an optional expansion board that adds 16 supervised inputs to the access control panel.
•
D-805 – The D-805 is an optional door expansion board that adds 4 reader inputs, 4 outputs (Form C, 5 A), and 8
supervised inputs to the access control panel.
•
P-805 – The P-805 is an optional expansion board that adds 16 supervised inputs and 8 outputs to the access
control panel.
Each extension board can be either located inside an ME-1515 enclosure or can be installed directly on a wall using
the included DIN rail attachment. Each ME-1515 can contain up to two extension boards of different types.
One extension board can also be connected to the AC-825IP control panel using the expansion slot.
AC-825IP Installation & User Guide
www.rosslaresecurity.com
19
