4) Installation of carburetor and intake silencer
4.1) Assembly of carburetor
Carburetor NOTES: Use the gasket set ROTAX Part No. 293834.
4.1.1) Assembly of float housing and float
General NOTES: When the carburetor is held upside down, the float bracket
must take up a horizontal attitude when free from load. The
tips of the bracket must be at the same height. Adjust them
if necessary. In this check the float and float chamber
should not have been fitted.
Instructions See Figure 9.
Proceed as follows to install the float housing :
Step Procedure
1 The assembly of the parts is identical to the disassembly in reverse order. See
also Chap. 6 Section: 2.1.2).
Step Procedure
1 Check the position of the float attachment (1) when installed.
2 The “ALTO” = top on the float (2) must be visible when they are installed.
3 Install and adjust the Bowden cable for the carburetor piston actuation in ac-
cordance with the operating instructions.
4 Set the adjusting screws (3) and (4) in accordance with the operating instruc-
tions.
