ATTENTION
Activate starter for maximum of 10 seconds only (without inter-
ruption), followed by a cooling period of 2 minutes.
Step Step Description Procedure
8 Reduce Throttle
Valve as required
Set linearized throttle position
so that the engine runs on idle.
Example (Symbolic) Reduce Throttle.
ATTENTION
Increasing engine speed is only permitted at steady oil pressure
readings above 3 bar.
Step Step Description Procedure
9 Check engine instru-
ments (Warning Indi-
cators and
Operational Limits)
and ensure compli-
ance with the operat-
ing limits.
HIC A: If a 12 V voltage drop
between Terminal 2 and Termi-
nal 8 (permanent or oscillating)
is detected perform Lane and
Ignition Check. See abnormal
operation if the voltage drop still
persists.
HIC B: If a 12 V voltage drop
between Terminal 2 and Termi-
nal 10 (permanent or oscillat-
ing) is detected perform a Lane
and Ignition Check. See abnor-
mal operation if the voltage
drop still persists.
Display CAN A/B: Check if oil
pressure has risen within 10
seconds after engine start and
monitor oil pressure.
Example (Symbolic) Warning Lamp A: Check
Warning Lamp B: Check
Pilot Display: Check
10 Generator Switching Increase engine speed above
2400 rpm and hold for 8
seconds.
Example (Symbolic) Increase Throttle Position
