Rotax 915 i A SERIES User Manual

Effectivity: 915 i A Series
Edition 0 / Rev. 0
BRP-Rotax Page 3-13
December 01 2017
Step Step Description Procedure
Example (Symbolic) Lane select Switch A: ON
6 Await Warning Indi-
cator A to extinguish
and consider slack
time.
HIC A: 12 V voltage drop be-
tween Terminal 2 and Terminal
8 for 3 seconds.
NOTE
After the voltage drop between Terminal 2 and
Terminal 8 changes back to 0 V wait approx. 3
seconds until continuing with the next step.
Example (Symbolic) Warning Lamp A: Check
7
Deactivate ECU Lane
B
HIC B: Disconnect Terminal 1
and Terminal 9 to turn OFF
ECU Lane B.
Example (Symbolic) Lane select Switch B: OFF
8 Observe engine
speed
Display CAN A/B: Check en-
gine speed.
Example (Symbolic) Pilot Display: Check
ATTENTION
Engine speed may not drop/increase more than 250 rpm. If the fuel
pressure is not within the limits, the cause must be determined. The
engine must not be put into service until the problem is rectified.
Step Step Description Procedure
9 Activate ECU Lane B HIC B: Connect Terminal 1 and
Terminal 9 to power ECU Lane
B.
Example
(Symbolic)
Lane select Switch B: ON
10 Await Warning Indi-
cator B to extinguish
and consider slack
time.
HIC A: 12 V voltage drop be-
tween Terminal 2 and Terminal
10 for 3 seconds.
NOTE
After the voltage drop between Terminal 2 and
Terminal 10 changes back to 0 V wait approx. 3
seconds until continuing with the next step.
