Step Step Description Procedure
Example
(Symbolic)
Warning Lamp B: Check
11 Reduce Throttle
Valve as required.
Set linearized throttle position
to reach an engine speed of
2000 rpm and continue with fuel
pump check.
Example
(Symbolic)
Set Throttle
NOTE
Lane A and Lane B have different sensor inputs. During Lane
and Ignition check, some sensor values are not displayed, de-
pending on the activation of the Lanes
Following sensor values are not available if Lane A is turned
OFF and Lane B is activated:
• Coolant temperature
• Exhaust gas temperatures from cyl. 1-4
• Ambient temperature
• Throttle lever position
Following sensor values are not available if Lane B is turned
OFF and Lane A is activated:
• Oil temperature
• Oil pressure
Page 3-14
December 01 2017
BRP-Rotax Effectivity: 915 i A Series
Edition 0 / Rev. 0
