Rotax OM-912 Maintenance Manual

Effectivity 914 Series
Edition 1 / Rev. 0
page 51
May 01/2007
d02623
73-00-00
BRP-Rotax
Maintenance Manual
200 mm
(7.88 in.)
310 mm
(12.6 in.)
110 mm (4.34 in.)
40 mm (1.57 in.)
75 mm
(82.95 in.)
130 mm
(5.12 in.)
*
*
00048
Fig. 73-42
00049
* Length of tubes depending on
installation conditions
Fig. 73-43
