rotork CMA Series Installation & Maintenance Instructions

51
14. Default Menu
14.2 Parameter Default Values
14.2.1 Basic Menu
PARAMETER DEFAULT VALUE
Position No default setting is a read parameter
Setpoint No default setting is a read parameter
Thrust or Torque No default setting is a read parameter
Local/Remote LOC - local
Manual Jog No default setting is a control
Close Limit (zero) Set to fully extended at factory
Open Limit (span) Set to fully retracted at factory
CMD 4 Set at factory via a 4 mA input
CMD 20 Set at factory via a 20 mA input
Command Signal Invert Set at factory to OFF
Transmitter Signal Invert Set at factory to OFF
Deadband 1.0%
STATUS No Default / status access
ADVANCED MENU No Default / menu access
DEFAULTS No Default / default access
14.2.2 Advanced Menu
PARAMETER DEFAULT VALUE
CPT 4 (Current Pos tx cal) Set at factory to output 4 ma
CPT 20 (Current Pos tx cal) Set at factory to output 20 ma
SPEED 100%
TURNS* No Default - Calculated from Close and Open limits
Open Direction* No Default - Calculated from Close and Open limits
Stall Time out 2.0 Seconds
Knob Disable Set at factory to OFF
FHSTCL No default setting / history clear access
Command Source Analog
INFORMATION ACCESS No Default / menu access
CONTROL CFG ACC No Default / menu access
RELAY ACC No Default / menu access
SPLIT RANGE No Default / menu access
ACTUATOR CONFIG No Default / menu access
14.2.3 Information Menu
PARAMETER DEFAULT VALUE
Actuator Starts No default setting is a read parameter
Amplifier Starts No default setting is a read parameter
Temperature No default setting is a read parameter
Software Version No default setting is a read parameter
* Only available on CMR Rotary actuators.
