rotork CMA Series Installation & Maintenance Instructions

63
16. Power Ratings
17. Rotork Sales and Service
If your Rotork actuator has been correctly installed and sealed,
it will give years of trouble-free service.
Should you require technical assistance or spares, Rotork
guarantees the best service in the world. Contact your local
Rotork representative or the factory direct at the address on
the nameplate, quoting the actuator type and serial number.
Local representative:
CML-100/250, CMQ-250/500, CMR-50/100/200
Current rating at nominal line voltages (A)
Ambient Type Power (W) 24 VDC 110 VAC 115 VAC 120 VAC 208 VAC 220 VAC 230 VAC 240 VAC
20 ºC CML 16.36 0.68 0.21 0.20 0.19 0.11 0.11 0.10 0.10
CMQ 26.90 1.12 0.35 0.33 0.32 0.18 0.17 0.17 0.16
CMR 23.14 0.96 0.30 0.29 0.28 0.16 0.15 0.14 0.14
-20 ºC CML 27.82 1.16 0.37 0.35 0.37 0.20 0.19 0.18 0.17
CMQ 40.39 1.69 0.53 0.51 0.49 0.28 0.27 0.26 0.25
CMR 31.46 1.32 0.41 0.40 0.38 0.22 0.21 0.20 0.19
-30 ºC CML 36.50 1.52 0.47 0.45 0.43 0.25 0.24 0.23 0.22
CMQ 52.60 2.19 0.68 0.65 0.63 0.36 0.34 0.33 0.31
CMR 34.50 1.44 0.45 0.43 0.41 0.24 0.22 0.21 0.21
-40 ºC CML 44.50 1.85 0.58 0.55 0.53 0.31 0.29 0.28 0.26
CMQ 59.50 2.48 0.77 0.74 0.71 0.41 0.39 0.37 0.35
CMR 37.50 1.56 0.49 0.47 0.45 0.26 0.24 0.23 0.22
CML-750, CMQ-1000, CMR-89/125/250
Current rating at nominal line voltages (A)
Ambient Type Power (W) 24 VDC 110 VAC 115 VAC 120 VAC 208 VAC 220 VAC 230 VAC 240 VAC
20 ºC CML 51.46 2.14 0.67 0.64 0.61 0.35 0.33 0.32 0.31
CMQ 41.46 1.73 0.54 0.52 0.49 0.28 0.27 0.26 0.25
CMR 59.50 2.48 0.77 0.74 0.71 0.41 0.39 0.37 0.35
-20 ºC CML 59.50 2.48 0.77 0.74 0.71 0.41 0.39 0.37 0.35
CMQ 59.50 2.48 0.77 0.74 0.71 0.41 0.39 0.37 0.35
CMR 59.50 2.48 0.77 0.74 0.71 0.41 0.39 0.37 0.35
-30 ºC CML 59.50 2.48 0.77 0.74 0.71 0.41 0.39 0.37 0.35
CMQ 59.50 2.48 0.77 0.74 0.71 0.41 0.39 0.37 0.35
CMR 59.50 2.48 0.77 0.74 0.71 0.41 0.39 0.37 0.35
-40 ºC CML 59.50 2.48 0.77 0.74 0.71 0.41 0.39 0.37 0.35
CMQ 59.50 2.48 0.77 0.74 0.71 0.41 0.39 0.37 0.35
CMR 59.50 2.48 0.77 0.74 0.71 0.41 0.39 0.37 0.35
Listed below are the nominal current ratings for the CMA:
A4 US
US
A4
US
A4
A4 US
