VIDEO IN by default is configured on INT (internal), meaning that the images displayed on the
meter will be those decoded from the signal at the RF input.
Configuring it on EXT (external), the meter will display in the measurement interface the
images coming from the composite video input on meter’s right side panel.
IMAGE FORMAT by default is configured on 16:9, but it can be configured also on 4:3. It
represents the format of the video decoded in the measurement interface.
ASI IN by default is set to OFF. Switching it ON when using the measurement interface will let
the instrument detect the Transport Stream, provide Service List and decode automatically the
first non encrypted service.
RF IN by default is set to N(50Ω). It can be switched to F(75Ω) to change the meter’s RF input
interface.
LTE FILTER by default is set to OFF. LTE Filter is used in Spectrum Analysis and
Measurement Interface to assure the Meter is capable to receive and decode correctly all TV
signals, even those near to the band (above 800MHz) allocated to the LTE carriers. Scope of
the filter is to simulate the presence of an external hardware LTE filter in the signal distribution
system to evaluate the impact of the LTE carriers on the available TV broadcast carriers.
BATTERY SAVING by default set to OFF. When switched to ON it automatically decrease the
screen brightness after 30 seconds of inactivity; furthermore, it will shutdown automatically the
meter after 5 minutes of inactivity. It is a combination of DISPLAY LIGHT and AUTO OFF
parameters with default configurations.
