2 | Installation | 2.2 | Connect SignalsEN-18
Manual | TM3-Primus
Use of Digital Audio Signals
Digital 2-channel Stereo signals can be connected to the unbalanced
RCA socket S/PDIF In (yellow). Power supply will be provided by the use
of the delivered USB connecting cable and the delivered external USB
mains adapter. A digital 2-channel Stereo signal also can be output using
the RCA socket S/PDIF Out (black).
S/PDIF Out
USB Micro-B USB-A
1.5 m
S/PDIF In
2.
1.
3.
1. Plug the RCA connector of your S/PDIF signal source to the yellow
socket on the rear side of the unit.
2. Plug the Micro-B connector of the delivered USB connecting cable to
the USB Micro-B connector of the unit.
3. Then plug the USB-A connector of the USB connecting cable to a
corresponding socket of the USB mains adapter or a computer to boot
TM3-Primus.
