4 | Instruments | 4.7 | Loudness BarEN-52

Manual | TM3-Primus

4.7 | Loudness Bar

Instrument

Scale mark for

the Target Level

Summed Loud-

ness value:

M, S, or I

Loudness scale

The Loudness Bar instrument shows the combined total loudness con-

sisting of the summed single channels of a signal. This instrument shows

a bargraph representing one of the three available measurements with

different integration time constants. For stereo sources, the L and R chan-

nels are summed. For 5.1 sources, the ﬁ ve main channels (5.0) are used

for the measurement.

Tolerance range

acc. to deﬁ nition

in Loudness

standard
