4 | Instruments EN-36
Manual | TM3-Primus
4 | Instruments
The following instrument types are available with the TouchMonitor TM3-
Primus to visualize individual aspects of the audio signals measured.
The instruments have been prepared in different ways and sizes to asure
the selection of different combinations as well as an optimized use of the
display space.
Therefore, instruments with large space requirements like Audio Vector-
scope (VSC), Loudness Chart or Real Time Analyzer (RTA), are alterna-
tively placed in the upper half of the screen.
Instruments with smaller shapes like PPM, Moving Coil, Correlator, Loud-
ness Sum, Magic LRA, Numeric, or the keys, are not spreading across the
whole width of the screen. Useful combinations of these are placed in the
lower half of the screen. The behaviour of the option keys while making
your selections in the setup menus will give you an immediate overview
about the instruments, which can be used in parallel or not.
The description follows the order the instruments have in the setup menu.
