EN-41Manual | TM3-Primus 4 | Instruments | 4.2 | Chart
EN
1. Touch and hold the screen for more than 2 seconds. The Main menu
appears.
2. Touch the Addnl. parameter option.
3. At fi rst, the Keys menu page appears. Touch Confi rm.
4. The Chart parameter menu page appears.
5. Make your settings. Select the display mode, the active graph, and the
time range. Defi ne, if you want to see the position of the Relative Gate,
the I-sum bargraph, and the tolerance marker. Set the individual tole-
rance range. Touch Confi rm.
6. On Monitoring menu page, again touch Confi rm. You will get back to
the main menu.
7. Touch Store to transfer the changes to the system. The unit gets back
to normal operation using the new settings.
