93
Configuring the Access Point
Configuring Ethernet Ports
Port Type See “Setting Ethernet Port Type” on page 95 for
more detailed information.
■ Trunk port: This port passes all VLAN traffic.
■ Access Port: This port provides network
access.
■ General Port: User-defined VLAN member-
ship.
Packet Forwarding Isolated: Selecting Isolated causes the traffic
from this port to terminate at the Access Point.
Bridge to WAN: The default setting, Bridge to
WAN forwards packets arriving on this port to the
WAN (uplink) port and eventually to their external
destinations using Layer 2 forwarding.
Local Subnet NAT and Route to WAN: This
setting allows routing of packets to their
destinations using Layer 3 network address
translation (NAT).
Bridge to L2TP Tunnel: Uses Layer 2 Tunneling
Protocol to deliver packets encapsulated with an
L2TP header in UDP datagrams.
Local Subnet This option appears if you have selected Local
Subnet and Route to WAN under Packet
Forwarding, and you have selected Access Port as
the port type. This option allows you to select
which subnet this port’s traffic will be part of. You
must have previously configured a subnet from
the Configuration > Local Subnets page before it
becomes available here.
