Installing the Access Point
ZoneFlex 7025 Physical Installation
Figure 31. Hook the locking tabs into the housing cutouts
You have completed the physical installation.
Using the 110 Punch down Block
CAUTION: Do not connect both the Punch-down block and the Uplink port to a
network. Only one connection can be used at a time.
If you prefer to use the 110 Punch-down block connector rather than the RJ-45
connector for power and network connectivity, refer to the following diagram for
wiring details.
To Next Page
