28
Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
ZoneFlex 7025 Wired/Wireless Wall Switch
The ZoneFlex 7025 is designed for installation in an electrical junction box. This section
identifies the physical features of each ZoneFlex 7025 Wi-Fi Wall Switch model that is
discussed in this guide. Before you begin the installation process, Ruckus Wireless
recommends that you become familiar with these features.
■ ZF7025-US Model
■ ZF7025-EU Model
ZF7025-US Model
This section describes the physical features of the ZF7025-US model, which is
designed to fit in a standard US-style wall electrical outlet box. The outlet box must
conform to NEMA-WD6, with a minimum depth of 1.4 inches.
Front View Features
The front view of ZF7025-US, shown in Figure 15, features a LAN port door which
covers the four Ethernet Ports, a pass through port and a DC in socket on the right
side. Refer to Tabl e 20
for more information.
