27
Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
CAUTION: The external antenna connectors are for indoor use only. Do not connect
them to outdoor antennas.
Table 18. ZoneFlex 2942 rear panel elements
Number Item Name Description
1 Power Connect the power adapter to this socket. (Input
110-240V AC, Output 12V 1.0A DC). Power can also
be supplied via 10/100 PoE port.
2 Lock Hasp The lock hasp works with a cable or Ruckus mounts.
The recommended lock type is Masterlock 120 series
(D, T, Q, KAD types).
3 External RP-SMA
Connector
External antenna connector
4 LAN Ports Two RJ-45 ports, supporting 10/100 PoE (Power over
Ethernet) and 10/100Mbps connections.
Each Ethernet port has two LEDs, which indicate the
type of device that is connected to the port.
5 OPTIONAL Button Not active in this model at this time.
6 SOFT RESET
Button
Used to reset the AP. This is a normal reset and does
not reset the AP back to factory defaults.
Table 19. Behavior of Ethernet port LEDs on ZoneFlex 2942
LEDs Description
Off Not connected
Amber + Green Connected to 10Mbps device
Amber Connected to 100Mbps device
Green Connected to 1000Mbps device
