Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
AIR LED • Off: The Access Point is operating as a
Standalone or RootAP.
• Green: The AP is functioning as a Mesh AP
(MAP), and the wireless signal to its uplink AP
is good.
• Fast flashing green (two flashes every second):
The AP is functioning as a Mesh AP (MAP), and
the wireless signal to its uplink AP is fair.
• Slow flashing green (one flash every two
seconds): Mesh networking is enabled, but the
AP is still searching for a mesh uplink.
2.4GHz LED • Off: The WLAN service is down.
• Green: The WLAN is up and at least one client
is associated.
• Amber: The WLAN is up. No clients are
associated.
5GHz LED • Off: The WLAN service is down.
• Amber: The WLAN is up, but no clients or
downlink MAPs are associated/connected.
• Green: The WLAN is up and at least one client
is associated. No downlink MAPs are
connected.
• Slow flashing green (one flash every two
seconds): The WLAN is up and at least one
downlink MAP is connected. No clients are
associated.
• Fast flashing green (two flashes every second):
The WLAN is up, at least one downlink MAP is
connected, and at least one client is
associated.
Table 3. ZoneFlex 7982 front panel elements
LED Description
