16
Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
WLAN LED • Off: The WLAN service is down.
• Amber: The WLAN service is up and no clients
are associated (standalone), or no wireless
clients and no downlink MAPs are connected
(RAP).
• Green: The WLAN service is up and at least one
wireless client is associated. If Mesh is enabled,
no downlink MAPs are connected.
• Fast flashing green: The WLAN service is up, at
least one client is associated, and at least one
Mesh downlink is connected.
• Slow flashing green: At least one Mesh
downlink is connected, and no clients are
associated.
AIR LED • Off: The WLAN service is down.
• Green: The AP is functioning as a RAP or MAP
and the uplink signal is good.
• Slow flashing green (one flash every two
seconds): Mesh networking is enabled, but the
AP is still searching for a mesh uplink.
• Fast flashing green (two flashes every second):
The AP is functioning as a MAP and the wireless
signal to its uplink AP is fair.
Table 11. ZoneFlex 7343 front panel elements
LED Description
