39
Installing the Access Point
Before You Begin
ZoneFlex 7341, 7343, 7363, 7321 and 7982 Orientation
ZoneFlex 7341, 7343, 7363, 7321 and 7982 have a more rounded coverage area and
less horizontal range (when mounted horizontally) compared to the dome-shaped
ZoneFlex 2942 and 7962 APs.
Figure 23. ZoneFlex 7341/7343/7363/7321/7982 recommended ceiling mounting
orientation
When wall mounted, ZoneFlex 7341, 7343, 7363, 7321 and 7982 should be staggered
to maximize coverage.
