Ruijie RG-S5750-H Series User Manual

Hardware Installation and Reference Guide Product Overview
32
Maximum
Voltage
90 V to 264 V
47/63 Hz
192 V to 288 V
Input Current
2 A
Output Voltage
12 V
Max Current
Output
5.83 A
Max Power
Output
70 W
Input Leakage
Current
≤1.75 mA
Dimensions
(L x W x H)
156 mm x 50.5 mm x 38 mm
Weight
≈0.395 kg
Temperature
Operating temperature: -10℃ to 50℃
Storage temperature: -40℃ to 70℃
Humidity
Operating humidity: 10% to 90%
Storage humidity: 5% to 95%
Altitude
0 m to 5,000 m
The HVDC input of the RG-PA70I power module is only applicable to the Chinese region.
Features
Feature
Description
Conformal Coating
Protects circuits against moisture, frog, mould, electrical shock and
leakage, and so on.
Protection
Provides protection over over-voltage/current input/output, short-circuit
output and so on.
I2C Communication
Allows the host to communicate with the power module by I2C.
Power Supply
Redundancy
Supports dual power modules to cooperate in parallel, enabling PE with
1+1 redundancy and redundant power supplies with current sharing.
Hot Swapping
Supports to disconnect one redundant power module from the outside
power supply system, plug and unplug power modules while the device is
powered on.
Power Supply Alarm
Alarms power supply faults through the power status LED.
LED
LED
Panel Identification
State
Meaning
Status
LED
DC OK
Off
There is no power input or input under voltage.
Solid
green
The module is operational.
