Hardware Installation and Reference Guide Product Overview
31
M5000H-04XS is only supported on the expansion module slot 1 of RG-S5750C-48GT4XS-H and
RG-S5750C-48SFP4XS-H. If expansion module slot 1 is installed with the M5000H-04XS module,
expansion module sot 2 does not support any expansion modules.
Module
Description
External port
M5000H-04XS
4-port 10GE optical
module
4 SFP+ ports
For the detailed description about the modules, see Switch Extension Module Manual.
1.8 Power Modules
At present, RG-S5750C-28GT4XS-H, RG-S5750C-28SFP4XS-H and RG-S5750C-48GT4XS-H series
switches support the swappable RG-PA70I and RG-PD70I power module. The RG-PA70I power
module provides AC (HVDC) input and DC output, 12V voltage output and up to 70W power output to
the switch. And the RG-PD70I power module provides DC input, 12V voltage output and up to 70W
power output to the switch.
RG-S5750C-48SFP4XS-H supports RG-PA150I-F.RG-S5750-48GT4XS-HP-H and RG-S5750-
24GT4XS-HP-H support RG-M5000E-AC500P, RG-M5000E-DC500P and RG-PA1150P-F. RG-
S5750C-28GT4XS-H, RG-S5750C-28SFP4XS-H and RG-S5750C-48GT4XS-H support only the
RG-PA70I and RG-PD70I power module. Do not apply other power modules.
RG-S5750C-48SFP4XS-H only supports RG-PA150I-F.
RG-S5750-48GT4XS-HP-H and RG-S5750-24GT4XS-HP-H only support RG-M5000E-AC500P,
RG-M5000E-DC500P and RG-PA1150P-F.
The switch can be powered by one power module, or two power modules. When both two modules
are available, the switch is powered in current sharing mode.
If the system uses dual power supplies and the working power is greater than the max power
provided by one single power supply, the redundancy function is not available. If one power supply
fails, the system function may be affected.
1.1.1 RG-PA70I
Specification
Power Model
RG-PA70I (AC input)
RG-PA70I (HVDC input)
Device Model
RG-S5750C-28GT4XS-H
RG-S5750C-28SFP4XS-H
RG-S5750C-48GT4XS-H
RG-S5750C-28GT4XS-H
RG-S5750C-28SFP4XS-H
RG-S5750C-48GT4XS-H
Rated Voltage
100 V to 240 V
50/60 Hz
240 V
