Ruijie RG-S5750-H Series - Page 68

Hardware Installation and Reference Guide Appendix A Connectors and Connection Media
64
Optical Fiber Connection
For the optical fiber ports, select single-mode or multiple-mode optical fibers for connection according to
the fiber module connected. The connection schematic diagram is shown in Figure A-4:
Figure A-4 Schematic Diagram for optical fiber connection
