Ruijie RG-S5750-H Series User Manual

Hardware Installation and Reference Guide Appendix B Mini-GBIC, 10G SFP+ and 40G QSFP+
Modules Specifications
66
2
SMF=Single-mode fiber
GE Mini-GBIC (SFP) Models and Specifications
Table B-2 Existing GE Mini-GBIC (SFP) Models Supported
Model
Wavelength
(nm)
Fiber
type
DDM
(Yes/No)
Transmit
(dBm)
Receive
(dBm)
Min
Max
Min
Max
MINI-GBIC-SX-MM850
850
MMF
No
-9.5
-3
-17
0
MINI-GBIC-LX-SM1310
1310
SMF
No
-9.5
-3
-20
-3
GE-eSFP-SX-MM850
1310
MMF
No
-9.5
-3
-17
0
GE-eSFP-LX-SM1310
1310
SMF
Yes
-9.5
-3
-20
-3
GE-SFP-LX-SM1310
1310
SMF
No
-9.5
-3
-20
-3
MINI-GBIC-LH40-
SM1310
1310
SMF
Yes
-2
3
-22
-3
GE-SFP-LX20-
SM1310-BIDI
1310TX/1550RX
SMF
Yes
-9
-3
-20
-3
GE-SFP-LX20-
SM1550-BIDI
1550TX/1310RX
SMF
Yes
-9
-3
-20
-3
GE-SFP-LH40-
SM1310-BIDI
1310TX/1550RX
SMF
Yes
-5
0
-24
-1
GE-SFP-LH40-
SM1550-BIDI
1550TX/1310RX
SMF
Yes
-5
0
-24
-1
MINI-GBIC-ZX50-
SM1550
1550
SMF
Yes
-5
0
-22
-3
MINI-GBIC-ZX80-
SM1550
1550
SMF
Yes
0
4.7
-22
-3
MINI-GBIC-ZX100-
SM1550
1550
SMF
Yes
0
5
-30
-9
GE-SFP-SX
850
MMF
No
-9.5
-3
-17
0
GE-SFP-LX
1310
SMF
No
-9.5
-3
-20
-3
When short-distant SMF modules are used based on the intensity of received lights, it is
recommended to add optical attenuators to the connection to avoid damage including: FE-SFP-
LX20-SM1310-BIDI, FE-SFP-LX20-SM1550-BIDI, FE-SFP-LH40-SM1310-BIDI, FE-SFP-LH40-
SM1550-BIDI, GE-SFP-LH40-SM1310-BIDI, GE-SFP-LH40-SM1550-BIDI, MINI-GBIC-LH40-
SM1310, MINI-GBIC-ZX50-SM1550, MINI-GBIC-ZX80-SM1550, MINI-GBIC-ZX100-SM1550,
SDH155-SFP-LH40-SM1310 and SDH155-SFP-LH80-SM1550.
The optical module is a laser device. Please take care of your eyes and do not look into the laser beam directly.
To keep the optical module clean, please make sure that the dust cap is mounted when it is not connected to cables.
Table B-2 (continued)
Model
Interface
Type
Fiber Type
Core Size (μm)
Cabling Distance
