SERVICE 7
29
7.19 TROUBLE SHOOTING
PROBLEM PROBABLE CAUSE REMEDY
Turf lifting Shallow rooted turf Increase turf guard
spring tension by adding
spacers above spring
Tines plugging Dirty and corroded tines Thoroughly clean tines
and lightly water greens
Burrs on tines Remove burrs with file
Oversized tires (rear)
Engine speed too slow Operate at max. speed
(3600RPM)
See tire specifications
Tines not penetrating turf Tines worn or plugged Replace or clean tines
Tines not lifting high enough Low hydraulic fluid Add hydraulic fluid
Tines won’t move Bent pushrod Replace pushrod
Dog clutches do not move Linkage out of adjustment Adjust linkage. See Dog
Clutch Adjustment sec-
tion, page 13
Master clutch slips Worn linings Rebuild or replace clutch
Oblong hole in turf Unit out of time Check timing. See Timing
section, page 16
Noise in camcase Unit out of time
Check timing. See Timing
section, page 16
