HYDRAULICS 8.12
59
29 547898 Cylinder, lift, 9210 & later w/O-ring fitting 2. . . . . . .
* 884648 •Seal Kit As Req’d Not illustrated.. . . . . . . . . . . . . . . . . . . . . . . . . . . .
30 545635 Cylinder, lift, prior to 9210 w/pipe fitting 2. . . . . . . .
* 545641 •Seal Kit (for cylinder w/ lock wire) As Req’d Not illustrated.. . . . . .
* 884648 •Seal Kit (for cylinder w/ lock ring As Req’d Not illustrated.. . . . . . .
31 547897 Pump 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
* 887063 •Seal Kit As Req’d Not illustrated.. . . . . . . . . . . . . . . . . . . . . . . . . . . .
32 4120673.7 Reservoir, hydraulic 1. . . . . . . . . . . . . . . . . . . . . . . . . .
33 545801 •Dipstick 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
34 548159 Washer, 5/16 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
35 548458 Pin, clevis 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
36 548604 Screw, 5/16–18 x 3/4 3. . . . . . . . . . . . . . . . . . . . . . . .
37 548882 Knob, lift lever 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
38 548910 Nut, flangelock 1/4–20 12. . . . . . . . . . . . . . . . . . . . . .
39 800855 Nut, 5/16–18 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
40 800059 Locknut, 1/4–20 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
41 814924 Clamp, hose 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
42 823118 Fitting, hydraulic (straight) 2. . . . . . . . . . . . . . . . . . . .
43 826558 Fitting, hydraulic (90° elbow w/o ring) 2. . . . . . . . . . .
44 827395 Fitting, hydraulic (90° adapter) 1. . . . . . . . . . . . . . . .
45 ♦ 523998 Hose, 9210 & later w/ O-ring fitting
(cylinder to support) 30″(762mm) 2. . . . . . . . . . . . .
or ♦ 828052 Hose, prior to 9210 w/pipe fitting
(cylinder to support) 30″(762mm) 2. . . . . . . . . . . . .
46 ♦ 523997 Hose, 9210 & later w/ O-ring fitting
(cylinder to support) 39″(991mm) 2. . . . . . . . . . . . .
or ♦ 828053 Hose, prior to 9210 w/pipe fitting
(cylinder to support) 39″(991mm) 2. . . . . . . . . . . . .
47 828056 Fitting, hydraulic 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
48 832794 Fitting, hydraulic (45° elbow) 1. . . . . . . . . . . . . . . . . .
49 ♦ 547896 Valve, selector (9210 & later) 1. . . . . . . . . . . . . . . . . .
or ♦ 885234 Valve, selector (prior to 9210) 1. . . . . . . . . . . . . . . . .
* 884599 •Repair Kit, valve (fits either valve) As Req’d Not illustrated.. . . . . .
50 103867 Washer, 5/16 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
51 306325 Lockwasher, 5/16 2. . . . . . . . . . . . . . . . . . . . . . . . . . .
52 306416 Screw, 5/16–18 x 1 2. . . . . . . . . . . . . . . . . . . . . . . . . .
53 306932 Nut, 5/16–18 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ref.
No.
Part
No.
Description Notes
No.
Req’d
•INDENTED PART NAMES INDICATE THESE PARTS ARE INCLUDED IN PRECEDING ASSEMBLY.
♦Greensaire 24 models 9210 and later, have an improved hydraulic lift system. This lift system required
new lift cylinders and hoses, a new pump and a new selector valve.
The new lift cylinders and lift cylinder hoses have ‘O’ ring connections instead of the old pipe fittings.
When ordering lift cylinders or hoses be sure the connections are compatible.
The new pump is a higher capacity pump. It can be used with either the new or old system. However, if
the new pump is used on an older unit (prior to 9210) we suggest also replacing the selector valve with
the new one that is configured to be compatible with the higher pressure pump.
The new valve can be used with both systems.
