2.16.2.1 ECDIS / Pilot systems input data and formats
The input data and formats are shown in Table 2-2 below. Details of
each sentence can be found in Ref. [3].
Additional information is given in Appendix [A.2] – Interpretation of
IEC 61162-1 sentences.
Table 2-2. High-speed input data and formats
Data IEC 61162-1 sentences
Normal access - parameter entry
Static station information:
(- Vessel name)
(- Call sign)
- Antenna location
- Length and beam
SSD - Station Static Data
(- not used, field sets to null by the R4)
(- not used, field sets to null by the R4)
- used to set the antenna location for the
external GPS only (saved in the R4
memory)
Voyage information:
- Vessel type and cargo category
- Navigational status
- Draught, max. actual static
- Destination
- ETA date and time
- Regional application flags
VSD - Voyage Static Data
Long Range acknowledgement
External manual LR acknowledgement LRF - Long Range Function
Initiate VHF Data Link broadcasts
Safety messages ABM - Addressed Binary Message
BBM - Broadcast Binary Message
Binary messages ABM - Addressed Binary Message
BBM - Broadcast Binary Message
Interrogation message AIR - AIS Interrogation information
Channel setting
Channel assignment message (set
frequency)
ACA - AIS Channel Assignment message
BIIT input
Alarm / indication acknowledgement ACK - Acknowledgement message
Own station settings queries
Query messages AIQ,ACA - Query AIS Channel Assignment
AIQ,SSD - Query Station Static Data
AIQ,VSD - Query Voyage Static Data
