2.16.2.2 ECDIS / Pilot systems output data and formats
The output data and formats are shown in Table 2-3 below. Details
of each sentence can be found in Ref. [3].
Additional information is given in Appendix [A.2] – Interpretation
of IEC 61162-1 sentences.
Table 2-3. High-speed output data and formats
Data IEC 61162-1 sentences
Prepared by AIS transponder
Notification that a session initiated by
messages ABM, BBM, ACA, AIR is
terminated
ABK - Acknowledgement message
AIS Own-ship broadcast data (all
transmissions available)
VDO - VHF Data-link Own-vessel message
Query response messages ACA - AIS Channel Assignment
SSD - Station Static Data
VSD - Voyage Static Data
BIIT results
AIS equipment status ALR - Alarm message
TXT - Status/indication message
Received from Long Range equipment
LR Interrogation LRI - Long Range Interrogation
LR Function identification LRF - Long Range Function
Received on VHF Data Link by AIS transponder
All VDL AIS messages received
- Broadcast or
- Addressed to own station
VDM - VHF Data link Message
