User Manual Laser Diode Controller PilotPC 16
Rear Panel
This section shows the rear panel elements.
On this side you find all connectors.
List of Rear Panel elements
Element Description
1 RS232 Interface Connector
2 GBIB Interface Connector
3 PE Switch
4 Safety Interlock Connector
5 Key Switch
6 USB Interface Connector
7 Piezo Input/Output Connector
8 Laser Connector
9 TEC Connector
A Current/Power Signal Modulation Input
B Current/Power Signal Monitor Output
2
3
4
1
5
9
6
7
8
A
B
