User Manual Laser Diode Controller PilotPC 12
Interlock Port
The interlock port is one of several safety features.
The port acts as input port for a safety contact and as an indicator port
which could drive a LED.
The port is internally hardwired to the laser power supply so that an
open interlock loop will directly cause a shut down of the laser.
Possible Interlock Configurations
Safety Swich
Optical coupled Output
