User Manual Laser Diode Controller PilotPC 29
Temp Setup
In the temp setup menu the user will find critical parameters which
could have influence on lifetime and reliability
Therefore this parameters could be secured.
When it is not allowed to change these settings the text “Secure” is
displayed on top of the menu.
How to lock and unlock is described in the programming manual.
The following parameters could be set.
Label Description
Sensor The driver supports 10K NTC and AD590
I-TEC Limit Max. allowed current for the TEC
TEC Powerup TEC will be switched automatically on when
the driver powered up.
TEC Polarity In POS position the TEC cools the laser down
when a pos current is floating otherwise the
TEC warms the laser up
P (KR) PID Temp Controller parameter
I (TN) PID Temp Controller parameter
D (TV) PID Temp Controller parameter
Sensor AD590
ITEC-Limit 4000 mA
TEC Powerup On
TEC Polarity Pos
P (KR)
10.00 A/K
I (TN)
250.00 s
D (TV) 250.00 s
Temperature Setup (Secure)
