User Manual Laser Diode Controller PilotPC 39
Current Coupling Modulation
Low Volt Input analog Range -20..+20V
High Volt Input analog Range -120..+120V
Low Volt Mode Transf: 28,2..310 mA/V
High Volt Mode Transf: 4,7..51,7 mA/V
(High Voltage Mode = Prescal ON)
Bandwidth(3dB): 6kHz
Laser Current Monitor *
2
Output Voltage Range: 0-10V
Transfer Function: 1V/300mA
*
2
This is Output is not available in the piezo option
Temperature Control
TEC Output
Output Type: Bipolar Constant Current Source
Compliance Voltage: 8V
Maximum Output Current: -2A to 2A
Current Limit Setpoint Accuracy:0.01A
Maximum Power: 16W
Sensor
Temperature Sensor: NTC or IC Temp Sensor AD590
Temp. Control Range : -5 to 30°C (AD590 and NTC)
Temp. Meas. Range AD590: -5 to 30°C
Temp. Meas. Range NTC: -5 to 50°C
Setpoint Resolution NTC: 0.001°C
Setpoint Resolution AD590: 0.001°C
Long Time Stability: 0.05°C
Thermistor Sensing Current: 50µA
Sensor Bias: 5V
Common Data
Dimensions
W x H x D: 270 x 110 x 320 mm
PowerLine
Line Voltage 110V / 115V / 230V
Line Frequency 50-60Hz
NOTES
All values relate to a one-hour warm-up period.
Operating Temperature: 0°C to 40°C
Storage Temperature: –25°C to 70°C
Humidity: 20–85 %, non condensing
