User Manual Laser Diode Controller PilotPC 43
Temperature Control
TEC Output
Output Type: Bipolar Constant Current Source
Compliance Voltage: 8V
Maximum Output Current: -4A to 4A
Current Limit Setpoint Accuracy:0.01A
Maximum Power: 32W
Sensor
Temperature Sensor: NTC or IC Temp Sensor AD590
Temp. Control Range : -5 to 30°C (AD590 and NTC)
Temp. Meas. Range AD590: -5 to 30°C
Temp. Meas. Range NTC: -5 to 50°C
Setpoint Resolution NTC: 0.001°C
Setpoint Resolution AD590: 0.001°C
Long Time Stability: 0.05°C
Thermistor Sensing Current: 50µA
Sensor Bias: 5V
Common Data
Dimensions
W x H x D: 270 x 110 x 320 mm
PowerLine
Line Voltage 110V / 115V / 230V
Line Frequency 50-60Hz
Power Supply <160VA
Operating Conditions
Operating Temperature: 0°C to 40°C
Storage Temperature: –25°C to 70°C
Humidity: 20–85 %, non condensing
Standing horizontal without fan obstruction
